- Size: 0.5
- Place of Origin: Ningbo
- Brand Name: helm tower
- Model Number: MS50
- Weight: 380.000 kg
HMS50 applications:
Engineering Machinery：26T road roller（MK series），forging manipulators，Bucket Wheel
Marine Machinery： marine deck crane ，port gantry crane equipment
Mining Machinery: heavy duty handling car，coal mine drill
- Size: 0.5
- Place of Origin: Ningbo
- Brand Name: helm tower
- Model Number: MS50
- Weight: 380.000 kg
HMS50 series displacement map:
Displacement Group | MS50-7 | MS50-8 | MS50-0 | MS50-1 | MS50-2 | |||||
Displacement (ml/r) | Full displ | Half displ | Full displ | Half displ | Full displ | Half displ | Full displ | Half displ | Full displ | Half displ |
3500 | 1750 | 4008 | 2004 | 4996 | 1747 | 6012 | 3006 | |||
Max power (kw) | 123 | 82 | 123 | 82 | 123 | 65 | 123 | 82 | ||
Theoric torque at 10MPa | 5231 | 2562 | 5990 | 2935 | 7467 | 2558 | 8985 | 4402 | ||
Rated torque (N. m) | 13077 | 14975 | 18667 | 22463 | ||||||
Rated pressure (MPa) | 25 | 25 | 25 | 25 | ||||||
Max pressure (MPa) | 40 | 40 | 40 | 35 | ||||||
Rated speed (r/min) | 40 | 40 | 40 | 35 | ||||||
Speed range (r/min) | 0-100 | 0-100 | 0-100 | 0-90 | ||||||
